Location Tracker Gateway

Easy to Install

Reliable and Precise

Indoor BLE Asset Tracking Gateway

Features

✽ Non-Intrusive: Installs everywhere, Beautiful futuristic design

✽ Easy to install: Powered either by USB Micro or Power Over Ethernet (POE)

✽ Reliable: Uses top quality parts manufactured in Europe and the United States.

✽ Precise: ML driven RSSI algorithm can be trained on location and provides the best indoor location in the market

About

The GAT 102 is an innovative development on the Industrial tracking and location field.

It tracks the Bluetooth Low Energy (BLE) devices and calculates its real-time position by an RSSI (Received Signal Strength Indication)

The location method has been optimized using a Machine Learning (ML) developed algorithm, that can be easily tailored to specific indoor locations where multiple path signal fouls the RSSI tri-lateration.

This product is agnostic and can be used on any GIS platform after the indoor location has been geo referenced.

You can use our own tracking software, and track events from any mobile or smart device.

sensornetwork

Sensor Network

Its design allows the installation of hundreds of networked Gateways.

Specifications

Power Supply: PoE (Ethernet)
Connections: USB A, Ethernet RJ 45 USB A Micro
Data Reading: Selectable from 1 S/ Sec.
Antennas: Built-in Bluetooth antenna
Indoor Location: BLE 4.2 RSSI based
Frequency Bands: 2.4 Ghz
WIFI protocol standards: IEEE 802.11 b/g/n
WIFI Power: 18dBm
WIFI Rate: 300Mbps
Stadards: Bluetooth 4.x、Bluetooth 5
BLE power: -40dBm~+4dBm
Programmable Rate: 1Mbps、2Mbps
Receiver sensitivity: -108dBm
Dimensions: 150 Dia x 30 Depth mm
Weight: 1 Kg/ 2Lb
Environmental: IP 65
Physical: Hard high-impact plastic
Temperature range: -10 C / 65C
Very Sensitive

Fivetimes more sensitivity

Precision

High noise immunity

Premium design

Patented technology

Non-Intrusive

Small footprint. Installed anywhere

Real Time

True Real Time. No sampling

Smart

Sensor can be updated

Optimal Indoor Location

The location method has been optimized using a Machine Learning (ML) developed algorithm, that can be easily tailored to specific indoor locations where multiple path signal fouls the RSSI tri-lateration.

Indoor Location

95%

Real Time Monitoring

100%

Sensitivity

100%

Location / Tracker Gateway Versions

We design and build several versions of this sensor. Please ask if you are not finding the best to match your application
  • 1.

    Wired

    Differential bus output is immune to noise. Daisy chain easy connection with snap on splash proof connector

    Read more
  • 2.

    Wireless

    LoRa, NB-IOT or Bluetooth 5.0 MESH. Make your choice or the best proven wireless connectivity. Other upon demand.

    Read more
  • 3.

    High Sensitivity

    Pressure wave special transducer for high senstivity is immune to acceleration. Ideal for Robotics

    Read more

Other Products

Need a custom sensor? We got it!
